Unifence Stop Block

By: Woodsmith staff
Here's a handy aid for making repeatable cuts on the table saw. An adjustable stop block that works with your Unifence gives you accurate flexibility.

Making consistent, repeatable cuts on the table saw is simple using a rip fence. But recently, while making stiles and rails for some frame and panel doors, I found it challenging to return the table saw fence to the exact same position after moving it to make some crosscuts with my miter gauge. To solve this problem, I came up with a stop block that attaches to my Unifence rail as you see here. The stop block allows me to return my table saw fence to an exact location to continue ripping stock.

The stop block consists of two main pieces, a runner and a stop block. The runner is just a rectangular blank sized to slide in the front channel of the Unifence rail. A counterbored hole drilled in the middle of the runner accepts a carriage bolt. The stop block has two rabbets cut on the back face to fit the slot in the fence rail. One end of the stop block features a threaded insert that accepts a bolt and nut. This allows me to make micro-adjustments to the fence position.

A hole drilled in the middle allows the carriage bolt to pass through. A washer and knob secure the two parts.

Published: Oct., 25 2018
